Hollyland Cosmo C1 SDI/HDMI Wireless Transmission System 1000ft
COSMO C1 is using the latest coding, decoding technology, and 5G wireless transmission technology. It can achieve ultra-low latency wireless video transmission. It has a transmission range over 1,000ft with a clean line of sight (LOS) when the transmitter is connected to 1 receiver. And，both transmitter and receiver are equipped with L-series battery plates and can also be powered by USB Type-C port and DC power input.
Features:
- As low as 40ms Transmission Latency 2.1000ft Wireless Transmission Range (LOS) 3.Supports Smart Channel Selection
- Transmitter Supports SDI Input, HDMI Input, and SDI Loopout.
- Receiver Supports 2*SDI Outputs and HDMI output
- Supports DC Power Supply, Battery, and USB Type-C Power Supply
- Supports UVC Pull-streaming
Specifications:
| Wireless Range | 1,000ft or 300m (Line-of-Sight) |
| Channel Bandwidth | 20 MHz |
| Frequency Range | 5.1~5.8GHz |
| Latency | As low as 0.04s |
| RF Power | ≤ 22 dBm |
| RF Sensitivity | -80 dBm |
| Wi-Fi | NO |
Interfaces
| Transmitter Antenna Ports | 2 x RP-SMA Male |
| Receiver Antenna Ports | 2 x RP-SMA Male |
| Transmitter Video Connectors | 1 x HDMI Input 1 x SDI Input 1 x SDI Loop out |
| Receiver Video Connectors | 1 x HDMI Output 2x SDI Output |
| Transmitter Other I/O | 1 x USB Type-C 1 x DC Power Input |
| Receiver Other I/O | 1 x USB Type-C 1 x DC Power Input |
| Embedded Audio | HDMI |
Format Support
| Video Format | HDMI: 480p60 1080i50/59.94/60 1080p23.98/24/25/29.9/30 |
Display
| Transmitter Panel Type | OLED |
| Receiver Panel Type | OLED |
Power
| Transmitter Battery Support | 1 x Sony L-Series / NP-F Type |
| Receiver Battery Support | 1 x Sony L-Series / NP-F Type |
| Transmitter Power Connector | Barrel (6 to 12V DC) Input |
| Receiver Power Connector | Barrel (6 to 12V DC) Input |
| Transmitter Power Consumption | Device: (<9 W) |
| Receiver Power Consumption | Device: (<9 W) |
General
| Transmitter Mounting | 1 x 1/4"-20 Female |
| Receiver Mounting | 1 x 1/4"-20 Female |
| Materials | Metal |
| Transmitter Dimensions | 115*70*32mm(The Battery Plate Exclude) |
| Receiver Dimensions | 115*70*32mm(The Battery Plate Exclude) |
| Transmitter Weight | 214g |
| Receiver Weight | 210g |
Packaging Information
| Package Weight | 750g |
| Box Dimensions (LxWxH) | 290*137*265mm |
Content List:
1 x Cosmo C1 Transmitter
1 x Cosmo C1 Receiver
4 x Antenna
2 x Mushroom Antenna
1 x Cold Shoe
1 x Peasecod Pan-tilt with Cold Shoe
1 x Type-C Converter
1 x Power Adapter
| SKU | CosmoC1 |
| Barcode # | 6970758742573 |
| Brand | Hollyland |
| Shipping Weight | 2.0000kg |
| Shipping Width | 0.400m |
| Shipping Height | 0.200m |
| Shipping Length | 0.300m |
